SimplEE Grey
Specify SimplEE with VENTORA Glass' advanced double glazing selections. Refer to Insight for more information.Â
Our SimplEE Grey IGU is made up of one side Clear glass and the other Grey Low-E.
Clear glass available in 4,5, or 6mm, Low-E Grey available in 4 or 6mm. Spacer options from 6-20mm.
Pairing a tinted Low-E glass — such as a grey or neutral-tint — with a clear glass panel gives the window both thermal and solar performance, whilst offering improved glare control.
Very low SHGC can be achievable: The tint absorbs a significant portion of the sun's energy, while the Low-E coating reflects infrared heat. Together they drastically reduce solar heat gain. subtle reflectivity and glare control, improving thermal insulation (less need for A/C) and greater solar control- tropical or high sun areas.
Glare reduction: This is where tinted Low-E excels when compared to clear options. The grey or neutral tint softens harsh sunlight, reducing glare and reflections (more comfortable, even light rather than blinding glare).
Features
Applications
Specifications
| Glass | Stock Size |
|---|---|
| 4mm Clear Float | 3660mm x 2440mm |
| 5mm Clear Float | 3660mm x 2440mm |
| 6mm Clear Float | 3660mm x 2440mm |
| 4mm Grey Float | 3660mm x 2440mm |
| 5mm Grey Float | 3660mm x 2440mm |
| 6mm Grey Float | 3660mm x 2440mm |
| 5mm Dark Grey Float | 3660mm x 2440mm |
| 6mm Dark Grey Float | 3660mm x 2440mm |
| 4mm Low Iron Acid Etched | 3660mm x 2440mm |
| 6mm Low Iron Acid Etched | 3660mm x 2440mm |
| 6mm Grey Acid Etched | 3660mm x 2440mm |
| 4mm Clear Low E | 3210mm x 2440mm |
| 5mm Clear Low E | 3210mm x 2440mm |
| 6mm Clear Low E | 3660mm x 2440mm |
| 4mm Clear Low E Soft | 3210mm x 2440mm |
| 5mm Clear Low E Soft | 3210mm x 2440mm |
| 6mm Clear Low E Soft | 3660mm x 2440mm |
| 6mm Neutral Low E | 3300mm x 2760mm |
| 6mm Neutral Low E | 5100mm x 3300mm |
| 6mm Grey Low E | 3210mm x 2440mm |
| 6mm Grey Neutral Low E | 3660mm x 2440mm |
| 6mm Grey Reflective | 3660mm x 2440mm |
Performance
Resources
AS 2208
SAI Global Registered
Over 20 Years Experience
