SimplEE Lam

Name: SimplEE Lam
Brand: VENTORA Glass
Availability: InStock

Specify SimplEE with VENTORA Glass' advanced double glazing selections. Refer to Insight for more information.

Our SimplEE LAM IGU is made up of one side Clear glass and the other Low-E Laminate.
Clear glass available in 4,5, or 6mm, Lam available in 6.38 Low-E Clear or Grey. Spacer options from 6-20mm.

This combination pairs a Clear laminated Low-E panel — safety glass with a built-in Low-E coating — with a standard clear panel in an IGU. It delivers energy performance along with safety, increased sound insulation, and enhanced UV protection in one.

**A grey-tinted laminated Low-E panel paired with clear glass in an IGU is also available - A thermal stress fracture risk assessment is recommended when selecting Grey Low-E Lam for an IGU makeup.

Features + –

Our SimplEE IGU range is made up of one side Clear/Grey glass and the other Energy Efficient Coated Glass ( Low-E)

Applications + –

Available in float or toughened combinations.
Windows and doors in homes aiming for high energy ratings, climate sensitive architecture.

Specifications + –

Glass	Stock Size
4mm Clear Float	3660mm x 2440mm
5mm Clear Float	3660mm x 2440mm
6mm Clear Float	3660mm x 2440mm
4mm Grey Float	3660mm x 2440mm
5mm Grey Float	3660mm x 2440mm
6mm Grey Float	3660mm x 2440mm
5mm Dark Grey Float	3660mm x 2440mm
6mm Dark Grey Float	3660mm x 2440mm
4mm Low Iron Acid Etched	3660mm x 2440mm
6mm Low Iron Acid Etched	3660mm x 2440mm
6mm Grey Acid Etched	3660mm x 2440mm
4mm Clear Low E	3210mm x 2440mm
5mm Clear Low E	3210mm x 2440mm
6mm Clear Low E	3660mm x 2440mm
4mm Clear Low E Soft	3210mm x 2440mm
5mm Clear Low E Soft	3210mm x 2440mm
6mm Clear Low E Soft	3660mm x 2440mm
6mm Neutral Low E	3300mm x 2760mm
6mm Neutral Low E	5100mm x 3300mm
6mm Grey Low E	3210mm x 2440mm
6mm Grey Neutral Low E	3660mm x 2440mm
6mm Grey Reflective	3660mm x 2440mm
